Scope Ring Options

[LAZY EYED SNIPER]

Have any questions about scope rings? Is there a particular model you like to use? Let's see some pics and discussion...



[njsportsman]

I have some questions about mounting rings. I have a 835 with the cantilever rifled barrel and as I said in another post I am going to use my rifle scope which is a Redfield Golden 5 Star 2X7 and I am thinking of using high mounts or should I get low profile mounts? Thanks



[LAZY EYED SNIPER]

When it comes to mounting and optic, the key factor is going to be your cheek weld.

The cantilever base is already raised above the bore, so the line of sight through the optic with high rings might make it difficult to maintain the proper cheek weld. It all boils down to fit. You'll want to bring the optic into your natural line of sight, not the other way around...



[MikeD]

As LES pointed put the mount is already a bit high, I would definitely go as low profile as i could for the given scope.



[Rossignol]

I have a question about determining ring height.

I'm considering something like a Nikon BDC scope, I think it's a 3-9x40.

Is there a rule of thumb to determine ring height? This would be for a bolt action rifle with two piece base.



[LAZY EYED SNIPER]

Manufacturers usually list their ring height measurements in the specs.

I had a long explanation in my head ready to type, but the folks at Brownell's have a much simpler solution...

http://www.brownells.com/.aspx/lid=10725/guntechdetail/Determining_Scope_Ring_Height



[Rossignol]

That seems easy enough.



[John Morris]

I put a Nikon 3-9x40 BDC on my ATR and used medium scope rings.

I have these

http://www.weaveroptics.com/rings_bases/rings/quad_lock/

There is about 1" between the scope and barrel



[Rossignol]

I put a Nikon 3-9x40 BDC on my ATR and used medium scope rings.

Do you have a pic? How much clearance between the barrel and objective lens?



[John Morris]

Also what I found is that the rule of thumb is if you use 44mm or below use medium and 50mm use the tall



[Rossignol]

So a 40mm objective lens with medium rings? How much clearance between the lens and barrel with that set up?



[John Morris]

I will get a picture up soon,



[John Morris]

Here is a pic



[John Morris]

And another showing the headspace



[Water Monkey]

I'm actually extremely satisfied with my DNZ reaper one piece scope mount. It's awesome.



[John Morris]

Woo hoo!



[John Morris]

Hey Monkey what optic are you running?



[Water Monkey]

Nikon P223 3-9x BDC - excellent scope.



[dieselmudder]

Second the Nikon.



[John Morris]

Just was wondering since I put the Nikon 3-9x40 BDC on mine. His just looked different
